QN-220E New Max. Gate Weight 800kg AC220V 50Hz Automatic Sliding Gate Opener
  • QN-220E New Max. Gate Weight 800kg AC220V 50Hz Automatic Sliding Gate Opener
  • QN-220E New Max. Gate Weight 800kg AC220V 50Hz Automatic Sliding Gate Opener
  • QN-220E New Max. Gate Weight 800kg AC220V 50Hz Automatic Sliding Gate Opener
  • QN-220E New Max. Gate Weight 800kg AC220V 50Hz Automatic Sliding Gate Opener

QN-220E New Max. Gate Weight 800kg AC220V 50Hz Automatic Sliding Gate Opener

QN-220E is the new Sliding gate opener.The open door weighs up to 800 kilogramsandis usedin homes.Its innovative gear motor,which meets international standards.canResponding to the most complex security requirements.
Contact Us PDF Download

QN-220E New Max. Gate Weight 800kg AC220V 50Hz Automatic Sliding Gate Opener

Product Advantages

Product Descroption

QN-220E is the new Sliding gate opener.The open door weighs up to 800 kilogramsandis usedin homes.Its innovative gear motor,which meets international standards.canResponding to the most complex security requirements.

Product Feature

  1. The motor will be automatically cut off when the temperature reaches the rated value.

  2. Turbo worm transmission mechanism, transmission stability.

  3. Auto-shuttering back the door against touching, Soft start and soft stop.

  4. Convenient installation, when power failure can open the clutch, manual opening.

Product Parameters

Item No.QN-220E
Input Voltage220V/50Hz
Motor speed1400r/min
Output torque22N.m
Motor power300W
Max gate weight800kg
Gate speed12m/min
Limit switchSpring/Magnetic NO/NC
Temperature-45°C~+65°C
Noise<56dB
Gear teeth19T/24T
Size(mm)311(H)x275(L)x202(W)
