QN-FC1200 1200-4000kg Frequency Conversion Automatic Electric Door Operator Sliding Gate Opener

The 1200-4000kg Frequency Conversion Automatic Electric Door Operator Sliding Gate Opener is a cutting-edge solution designed to provide efficient and reliable operation for sliding gates in a wide range of applications.
Contact Us PDF Download

QN-FC1200 1200-4000kg Frequency Conversion Automatic Electric Door Operator Sliding Gate Opener

Product Advantages

Overview

The 1200-4000kg Frequency Conversion Automatic Electric Door Operator Sliding Gate Opener is a cutting-edge solution designed to provide efficient and reliable operation for sliding gates in a wide range of applications. This robust and technologically advanced gate opener is engineered to meet the demands of heavy-duty gates, offering enhanced security, convenience, and longevity.

Features

Energy-saving and efficient frequency conversion motor, built-in control board.

Automatic closing function, adjustable speed

automatic closing within the time.

Soft start and stop

rebound in resistance

Overheating protector

external infrared device anti-collision anti-clip acceptable

Interface for card reader, password, face recognition, and remote control of mobile phone.

Manual clutch when power failure

QN-FC1000 1200-4000kg Frequency Conversion Automatic Electric Door Operator Sliding Gate Opener

Product Parameters

Parameters
modelQN-FC1200QN-FC1500QN-FC2000QN-FC3000QN-FC4000
Power supply220220220220220
Input VoltageAC220AC220AC220AC220AC220
Working temperature-20°C~+50C-20°C~+50C-20°C~+50C-20°C~+50C-20°C~+50C
Max. Gate Weight12001500200030004000
Limit modeMagneticMagneticMagneticMagneticMagnetic
Remote control frequency433433433433433
Running Speed4~26M/min4~26M/min4~26M/min4~26M/min4~26M/min
Max. Remote control Q'ty125125125125125
