The Side Mounted Automatic Door Opener is well-suited for a wide range of applications, including office buildings, retail spaces, healthcare facilities, and private residences. Its versatile design and advanced features make it adaptable to various entryways and usage scenarios.
Features
Ultra-quiet:the noise during operation is less than 50dB
Low power consumption:static power 0.5w, rated power 25w
Small size: small size, small space occupied, convenient installation
Large power:maximum pushable door weight 140KG
Supports multiple signal inputs, relay signal, voltage signal 5-24V
Motor overcurrent, overload, short circuit protection
Intelligent resistance, push door Reverse protection
Motor current (thrust):precise speed adjustment
Self-learning limit, no need for limit debugging
Enclosed housing, dustproof and rainproof
| Parameters | |
| Model | QN-200 |
| PowerSupply | DC24V |
| Motor | DC |
| Door Opening Anale | 90 Degree |
| Rated Power | 60W |
| Static power | 0.5W (No electromagnetic lock) |
| Rated Current | 5A |
| Keep the door open | 1-99 second |
| Opening / closing speed | Adjustable in 1-9 gears (corresponding to door opening time 10-3S) |
| Operating Ambient Temperature | -20℃+60℃ |
| Operating environment humidity | 30%-95%(No condensation) |
| Operating Ambient atmospheric pressure | 700hpa-1060hpa |
| Weight | ≈6.3KG |
| Maximum width of a single door(M) | 1.6 m |
| With The Door Weight(KG) | 120KG |
| Product size (mm) | 300(L)*80 (W)*140(H) |
